Proposed Real Time Data Acquisition System Network
Sub-Basin Krishna
To Be Upgraded Newly Proposed Total
Bhima
To Be Upgraded Newly Proposed Total
Automated Rainfall Stations
51 16 67
41 41 82
Automated River Water Level(Stage) & River Discharge Stations
10 03 13
14 04 18
Automated Reservoir Water Level & Outflow Discharge Stations
00 19 19
00 27 27
Automated Full Climate Stations
07 07 14
12 14 26
Grand Total
68 45 113
67 86 153
Total = 113+ 153 = 266
Note:
  • 3 GD stations of the CWC & 29 FCS stations of the ISRO/IMD are also part of the network. Data of these stations will be taken from respective data centre.
  • Review of the network will be taken by the consultants appointed.
Proposed Real Time Data Acquisition System Network is as shown in figure 2 & figure 3 below:
Figure 2 : Proposed Real Time Data Acquisition System Network in Krishna Basin
Figure 3 : Proposed Real Time Data Acquisition System Network in Bhima Basin
